Teclite 600R
In applications were two materials are sliding over each other, sometimes a spontaneous jerking motion together with noise can occur, also known as slip stick. Our teclite 600R material has a special layer, that will prevent stick slip or a slip-stick-motion and make the application soundless.
The resin in the Teclite 600R sliding bearing material is mixed with additives combined with a special fibre fabric that helps reduce the mechanical characteristics (in particular the friction coefficient) to extremely low values. The physical and mechanical characteristics of the Teclite 600R sliding bearing material make it the ideal self-lubricating bearing material for both dry and wet conditions. This material stands out particularly thanks to its very low friction coefficient while still remaining high wear resistance under heavy load conditions, for example in crane and bridge building.
What is Teclite?
Teclite is the collective term for a series of modern composite bearing materials. In the world of sliding bearings, Teclite sliding bearings and spherical bearings represent a perfect maintenance-free alternative for lubricated metallic/bronze bearing systems.
Teclite is composed of finely woven fibres that are impregnated with polyester resins. The physical and chemical characteristics of the Teclite composite material can be influenced to meet the needs of specific applications. The high load-bearing capacity, wear resistance and self-lubrication characteristics, together with the anti-corrosive behaviour of these maintenance-free composite materials mean that Teclite composites are ideally suited for the most challenging movement-related applications.
Characteristics of Teclite 600R
- Self-lubricating and maintenance free
- Wear resistance
- Low expansion coefficient
- Dimensional stability, also in wet environments
- 1/6 the weight of steel
- Ideal for inclination compensation
- Vibration damping
- Very high load resistance
- Very little to no stick-slip
Range
Our composite tube and rod material is available in several variants: each variant has its own unique characteristics to meet the needs of a specific application. Our stock range of composites are suitable for use in most conditions. In addition to Teclite 100G, our range includes:
- Teclite 100 composite sliding bearing material
- Teclite 300 composite sliding bearing material
- Teclite 600 composite sliding bearing material
Please contact us to ensure you make the right choice, or for more information about our composite materials. Our staff will be happy to advise you on all the possibilities.
We can produce tailor-made solutions for practically every specific application from sheet material and tube / rod material. We also supply unmachined material to clients with their own machining facilities.
Installation
To guarantee the perfect performance of composite bearings, correct assembly is essential, with the perfect dimensions. To ensure the correct bearing dimensions, we carry out technical calculations to determine the perfect fit and end play, according to the customer’s shaft / mortice and tenon / housing sizes. We can offer support during installation and on request will provide full assembly support.
Uses of Teclite 600R
- Offshore – Drilling rigs
- Inland shipping – Vessels
- Civil engineering – Bridges/locks
- Agriculture – Hydraulic systems
- Mechanical engineering – Food industry
- Construction – Cranes
Want to know more about Teclite 600R ?
Together with you, we translate technical challenges into tailor-made solutions. Optimal service is therefore the standard for us. Extensive material knowledge is linked to a broad experience in specific applications. The result? A competitively priced offer and high-quality components and assemblies.
For more information, we can also be reached by phone and e-mail. Tel: +31 (0)10 43 700 65 / E-mail: info@bbsindustrie.com
